3.2 Programming DR4088RB with further DR4088 at S88(N) connecon

It is important that the DR4088RB-xx must receive the module address once so that the DR4018RB-xx knows which module address it starts with. In addion, the

DR4088RB-xx must be informed that it consists of X mes 8 feedbacks.

This means:

If another DR4088xx is connected to the S88 connecon of the DR4088RB-xx, the number of modules increases from 2 to 4.

If the DR4088RB-xx a second DR4088xx is plugged into the S88 connecon, the number of modules increases from 4 to 6, and so on.

etc.

Aenon! A maximum of four DR4088xx can be connected to the S88 connecon on each string consisng of one DR4088RB-xx. This means that the DR4088RB-xx

is assigned module address 1 and then the number of modules 10 is transferred. This means that a maximum of 80 feedbacks are available on string 1.

If a second line is now set up at the R-Bus® , it starts with module address 11. Here, too, a maximum of 4 addional DR4088xx can be connected to the S88 con-

necon of the DR4088RB-xx. The second step here is to transfer the number of modules 10 to the DR4088RB-xx. A maximum of 80 feedback modules are now also

available on this line.

3.2.1 Programming with the DR5000

1. Open the DR5000 Tool

2. Properes Call XN-FB Bus

3. FB Call Programming Module

4. Now just follow the instrucons in the wizard.

Please refer to the instrucons above for programming the number of modules.

Example:

DR4088RB-xx —> DR4088xx

Modul address 1

Number of modules = 4 (x 8 feedback units)
