Callout Component Description
6 Power LED ()
7 Digital Pmods
8 JTAG header
9 User slide switches
10 User LEDs
11
OLED () display
12 Dual analog/digital Pmod
13 User pushbuttons
14 FMC HPC
15 Fan header
16 VADJ jumper
17 micro SD slot
18 3.5mm audio jacks
19 DisplayPort source connector
20 DisplayPort sink connector
21 VGA connector
22 HDMI source connector
23 FPGA configuration source jumper
24 HDMI sink connector
25 Power switch
26 Power jack 12VDC
Table 1. Genesys 2 features and connectors.
The Genesys 2 comes with an out-of-box demo design that gets loaded from the on-board QSPI flash. It exercises most of the
on-board peripherals. Just power the board with the included 12V wall supply, flick the power switch, wait for the design to
fully load and explore the following features:
