Lock Interface Overview
35
Key Guide:
• Provides management access
• Provides external power
• Each lock accepts up to (25) Manager Key(s)
• Minimum of (1) required per location
Manager Bypass Key (Black)
• Registers Manager Bypass Key(s)
• Provides external power
• Each lock accepts only (1) Programming Key
• Minimum of (1) required per location
Programming Key (Yellow)
• Registers Manager Bypass Key(s)
• Provides external power
• Each lock accepts only (1) Programming Key
• Minimum of (1) required per location
3rd Generation - Programming Key (Red)
• ADA Compliant User Key
• Optional
ADA User Key (Blue)
Pull Handle
C Button Key Symbol Button
Key Insert
LED light Usage Indicator
Alpha Numeric Keypad
Key Insertion
Digilock Logo must face up.
