Digilock DK-ATS - Digilock Wood Surface Mount Installation Steps

18
Note: For demonstration purposes the standard body with pull-handle and dead bolt rear unit will be shown.
A
1-Front Unit
D
1-Pin Extender
E
2-Phillips Head Screws*
F
2-Split Lock Washers
B
1-Plastic Ring
C
1-Rear Unit
Digilock Wood Surface Mount Lock Parts
Required Tools
Phillips Screwdriver
Head Size #2
* Screws lengths vary based on door thickness.
Installation Instructions
