Digilock Lock Parts
Note: Conrm that all lock parts are present. If there are damaged or missing parts contact your
Digilock Product Support Specialist.
1-Front Unit with Screw Posts
(Both body styles shown)
No-Pull
With-Pull
Optional-Back Plate2-Locking Nuts1-Plastic Ring
1-Motorized Rear Unit
(Both Dead Bolt & Dead Latch shown)
Dead Bolt
Dead Latch
Required Components
Warning: Do not use an electric screw gun during installation of the
lock unless equipped with a torque adjuster, which must be set on a
low torque setting. Otherwise, damage may be caused to the lock.
Required Tools
3/8” Socket
(deep socket required)
Phillips Screwdriver
Head Size #1 & #2
Hack Saw Metal File
For padlock hasp removalFor lock installation
