Digilock DK-ATS - Page 63

2.80 in
(71 mm)
2.80 in
(71 mm)
2.64 in
(67 mm)
1.35 in
(34 mm)
3.73 in
(95 mm)
2.64 in
(67 mm)
1.35 in
(34 mm)
3.71 in
(94 mm)
0.50 in
(13 mm)
0.50 in
(13 mm)
0.25 in
(6 mm)
0.25 in
(6 mm)
Motorized Dead Bolt
Motorized Dead Latch
60
Rear Unit Dimensions
