Digital Projection
Titan Q
uad / 800 / 930 Series
SCREEN REQUIREMENTS
Reference Guide
126
Rev H October 2013
WUXGA images displayed full height
Notes
Only WUXGA or UXGA
images
can ll the full height of the DMD
™
,
using all 1200 pixels without scaling.
full height = 1200 pixels
WUXGA = 16:10 = 1.6:1 = 1920 pixels
UXGA = 4:3 = 1.33:1 = 1600 pixels
