Digital Projection Titan Quad / 930 / 800 Series SIGNAL INPUTS AND OUTPUTS Connection Guide
32
Rev H October 2013
3D Sync in
• Sync input signal.
Connect the 3D sync from your graphics card or server.
3D Sync out
• Sync output signal. This may be affected by the Sync Offset and Output Sync Polarity
settings in the 3D menu.
Connect this to your IR emitter or ZScreen.
Side Connection Panel
1
2
Notes
For a complete listing of pin
congurations for all signal and
control connectors, see Appendix
E: Wiring Details in the Reference
Guide.
6
43 5
1
Sync In
2
Sync Out
3
3D input
4
3D Sync In
5
3D Sync Out
6
IR emitter or ZScreen
