Digital Projection Titan Quad / 930 / 800 Series USING THE PROJECTOR Operating Guide

Rev H October 2013

Geometry Engine (continued)

Cornerstone

If Cornerstone is selected from the main Geometry page, you can use

the sliders to stretch the image from each of the four corners.

Notes

Main Menu

Geometry

Cornerstone

Upper Right X and Upper Right Y correction
