DigiTech BASS SYNTH WAH User Manual

DigiTech
8760 South Sandy Parkway
Sandy, Utah 84070
PH (801) 566-8800
FAX (801) 566-7005
DigiTech and X-Series are trademarks
of the Harman Music Group Inc.
Copyright - Harman Music Group
Bass Synth Wah Envelope Filter
Owners Manual 18-1813V-A
Please visit DigiTech
on the World Wide Web at:
www.digitech.com
Printed in China
SPECIFICATIONS:
• Controls - Sens, Control, Range,Type,
On/Off Pedal
• Jacks - Input, Out 1 Normal (Dry),
Out 2 (Effect)
• Input Impedance - 1 MOhms
• Output Impedance - 100 Ohms
• Power Supply - 9V Alkaline Dry Battery
• Power Consumption - 4.8Watts
(w/optional PS200R power supply)
• Battery Life - Approximately 4 hours
(with continuous usage)
• Dimensions - 4 15/16”(L) x 3 1/8”(W)
x 2 1/8”(H)
• Weight - 1.38 lbs.
• Optional Power Supply
PS200R - 100 (100V ~ 50/60Hz)
PS200R - 120 (120V ~ 60Hz)
PS200R - 230 (230V ~ 50Hz)
PS200R - 240 (240V ~ 50Hz)

DigiTech BASS SYNTH WAH Specifications

Power

power supply	9V Alkaline Dry Battery
power consumption	4.8 Watts
optional power supply	PS200R - 100 (100V ~ 50/60Hz), 120 (120V ~ 60Hz), 230 (230V ~ 50Hz), 240 (240V ~ 50Hz)

Electrical Specifications

input impedance	1 MOhms
output impedance	100 Ohms
battery life	Approximately 4 hours (with continuous usage)

Weight and Dimensions

dimensions	4 15/16” (L) x 3 1/8” (W) x 2 1/8” (H)
weight	1.38 lbs
