4. Range Knob
Controls different functions depending on which Bass Synth Wah
Type is selected. See Effects Matrix on this page for detailed
Range knob descriptions.
Type SENS CONTROL RANGE
1- Env Filter Trigger Sensitivity Wet/Dry Mix Range
2- Sub Env Trigger Sensitivity Wet/Dry Mix Range
3- Synth 1 Trigger Sensitivity Synth Attack Cutoff Freq
4- Synth 2 Trigger Sensitivity Synth Attack Cutoff Freq
5- Filter 1 Trigger Sensitivity Filter Attack Freq Envelope
6- Filter 2 Trigger Sensitivity Filter Attack Freq Envelope
7- OctaSub Trigger Sensitivity Sub Level Synth Level
Effects Matrix

DigiTech BASS SYNTH WAH Specifications

Power

power supply	9V Alkaline Dry Battery
power consumption	4.8 Watts
optional power supply	PS200R - 100 (100V ~ 50/60Hz), 120 (120V ~ 60Hz), 230 (230V ~ 50Hz), 240 (240V ~ 50Hz)

Electrical Specifications

input impedance	1 MOhms
output impedance	100 Ohms
battery life	Approximately 4 hours (with continuous usage)

Weight and Dimensions

dimensions	4 15/16” (L) x 3 1/8” (W) x 2 1/8” (H)
weight	1.38 lbs
