DigiTech iStomp User Manual

9
Audio Connections
TheiStomphasstereo1/4”audioinputsandoutputs.ThepedalthatisloadedintotheiStomp
willdeterminewhichinputsandoutputsareactive.Formonoinpedals,onlyIN1isactiveand
canbeused–IN2isdisabledonallmonoinpedals.FromtheStompShopapp,taptheINFO
buttonforthepedaltoviewitscableconnectionrequirements.Whenusingmonoin
pedals,bothoutputswillbeactiveandcanbeused.
WhenstereopedalsareloadedintotheiStomp,youhavetheoptionofusingthepedalina
monoorstereoconguration.Therefore,youcanusetheIN1andOUT1connections(mono),
theIN1andbothOUT1andOUT2connections(monoin/stereoout),orbothIN1/IN2
andOUT1/OUT2connections(stereoin/stereoout).Connectiondiagramsareprovidedon
theproceedingpages.

DigiTech iStomp Specifications

General

Brand	DigiTech
Model	iStomp
Category	Music Pedal
Language	English
