DigiTech iStomp - Interface Components Part 1

5
1. Indicator LED–ThismulticolorLEDindicateswhentheeffectisturnedon
oroff.IfadelaypedalisdownloadedintotheiStomp,thisLEDwillflashwhen
usedwithTapTempotoshowthedelaytime(seepage13“DelayTapTempo”for
informationonTapTempo).UsingtheStompShopapp,thecolorofthisLEDcanbe
customizedforeachdownloadedpedal.
2. OUT 1 (Mono) Jack–Connectthisoutputwhenonlyasingleguitaramplifieris
beingused.
3. OUT 2 Jack –Connectthisoutputtoasecondguitaramplifierwhenasecond
ampisbeingused.
4. DC Power Input–Connectonlytheincludedpowersupplytothisjack.
5. Knobs –Theseknobsareusedtocontrolthepedalsettings.Thefunctionofeach
oftheseknobsvariesdependingonwhichpedalhasbeenloadedintotheiStomp.
Knobassignmentsforeachpedalcanbeviewedinthe“Info”windowintheStomp
Shopapp.
