DigiTech RP360 User Manual

102
RP360 / RP360 XP
MODULATION – PITCH SHIFT MODELS
• Octave
(Based on a Boss
®
OC-2 Octaver)
Based on the Boss OC-2 Octaver, this pedal adds two signals to your original guitar signal� The
first is one octave below your guitar, and the second is two octaves below your guitar� Each
additional signal has its own volume control�
Parameters
NAME OPTIONS OR RANGE DESCRIPTION
ON/BYP ON, BYPASS Turns the effect on and off�
OCTAVE 1 0 - 99 Adjusts the level of the effect signal 1 octave below the input signal�
OCTAVE 2 0 - 99 Adjusts the level of the effect signal 2 octaves below the input signal�
DRY LEVL 0 - 99 Adjusts the level of the dry (unprocessed) signal�

DigiTech RP360 Specifications

General

Looper	40 seconds
Drum Patterns	60
Display	LCD
USB	Yes
Power Supply	9V DC
Footswitches	3
Type	Multi-effects
Effects Types	Distortion, Overdrive, Chorus, Flanger, Phaser, Delay, Reverb, Wah
Inputs	1 x 1/4" Instrument
Headphones	1/8" Stereo
Expression Control	Yes
