83
RP360 / RP360 XP
EQ
The 3-band semi-parametric EQ is used to further shape your tone and provides low, mid, and high-
band controls, each with adjustable frequency and bandwidth�
Parameters
NAME
OPTIONS OR
RANGE
DESCRIPTION
ON/BYP ON, BYPASS Turns the effect on and off�
LOW LEVEL -12 dB to +12 dB Adjusts the level of the low frequencies (bass)�
LOW FREQ 60 Hz - 500 Hz Sets the center frequency of the low filter�
LOW BW
WIDE, MEDIUM,
NARROW
Sets the width of the low filter�
MID LEVEL -12 dB to +12 dB Adjusts the level of the midrange frequencies (mids)�
MID FREQ 300 Hz - 4 kHz Sets the center frequency of the mid filter�
MID BW
WIDE, MEDIUM,
NARROW
Sets the width of the mid filter�
HIGH LEVEL -12 dB to +12 dB Adjusts the level of the high frequencies (treble)�
HIGH FREQ 2 kHz - 8 kHz Sets the center frequency of the high filter�
HIGH BW
WIDE, MEDIUM,
NARROW
Sets the width of the high filter�
