Operator's Manual DS7A - Constant Current Stimulator
Rear Panel
Equipotentiality Connector
Digitimer have declared that this
equipment complies with the Medical
Device Directive under the supervision
of Notified Body 0120 (SGS UK Ltd.)
0120
Trigger Input - signal input connector.
Positive going pulse required Output - signal output connector.
Active "high" square wave
pulse produced
Foot switch connector.
Note: Only connect to other Medical
Digitimer Ltd. 20 of 58 Copyright © 2014
File Ref: N:\Docs\Company\Manuals\DS7A\Issue-14\DS7A-iss14.odt Last Revised: February 1, 2017
