Operator's Manual DS7A - Constant Current Stimulator
Explanation of Symbols Used on Accessories
The majority of these symbols comply with and are documented in ISO 15223: 2012.
Accessories
Plus; positive connection of
connection to patient (Anode)
Minus; negative connection of
connection to patient (Cathode)
Output - signal output connector.
Note: Only connect to other Medical
Equipment.
Type BF applied part
Digitimer have declared that this
equipment complies with the Medical
Device Directive under the
supervision of Notified Body 0120
(SGS UK Ltd.)
Consult operator
documentation (this manual)
before use of this equipment.
0120
Digitimer Ltd. 35 of 58 Copyright © 2014
File Ref: N:\Docs\Company\Manuals\DS7A\Issue-14\DS7A-iss14.odt Last Revised: February 1, 2017
