Off No physical connection to network
(LAN1)
On Network Connected (LAN2) LAN2
Off No physical connection to network
(LAN2)
On Network Connected (LAN3) LAN3
Off No physical connection to network
(LAN3)
On Network Connected (LAN4) LAN4
Off No physical connection to network
(LAN4)
On USB device connected (USB1)
Blinking Connected USB device not
supported (USB1)
USB1
Off No physical connection to USB
device (USB1)
On USB device connected (USB2)
Blinking Connected USB device not
supported (USB2)
USB2
Off No physical connection to USB
device (USB2)
2.3 Typical Usage
The following diagram shows a typical usage and connection of the
Router and computers. All PCs connected to LAN ports can access
the Internet via ISP’s ADSL or cable modem connected to WAN
port.
WAN
LAN1
LAN2
LAN3
LAN4
Router
ISP’s ADSL or Cable Modem
PC5
PC4
PC3
Switch/HUB
PC1
PC2
5
