1.2 FEATURES
This HDMI Extender has many features that enable it to perform in a superior
manner. Among those features you will find:
One pair as a full functional module, no need of setting.
One piece of CAT-5e/6 cable can substitute HDMI cable to achieve long
distance transmission.
Follow the standard of IEEE-568B.
Transmission distance can be up to 50 meters for 1080p using UTP cable with
cross stand inside.
Auto-adjustment of feedback, equalization and amplify, the user does not
need to care about the length of the cable.
Compact size.
Supports highest video resolution 1080p.
Supports 165MHz/1.65Gbps per channel (4.95Gbps all channel) bandwidth.
Supports 8bit per channel (24bit all channel) deep color.
Supports uncompressed 2 channel audio such as LPCM
2.0 SPECIFICATIONS
Signal Inputs/Output
Input Video Signal 0.5 -1.0 volts p-p
Output Video HDMI
Video format supported
DTV/HDTV 480i/576i/480p/576p/720p/1080i/1080P
Transmission distance
UTP cable with cross stand inside 50M for1080p
Operating Frequency
Video Amplifier Bandwidth 1.65Gpbs/165MHz
Vertical Frequency Range 50/60Hz
Resolutions(HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p
Mechanical
Size (L-W-H) 100×65×25.5MM
Weight (Net) 385G
Warranty
Limited Warranty 2 Years on Parts and Labor
Environmental
Operating Temperature 0 to +70
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature -10 to +80
Storage Humidity 5% to 90 % RH (no condensation)
Power Requirement
Power Supply 5V DC@2A
Power consumption (Max) 5W
