Installation
2. Connections
2.1 Point to Point connection:
Up to 120 meters transmission distance over single CAT 6 (High quality
cable can reach 150 meters).
2.2 Network Switch/Router Connection:
By using network switch/router/repeater, realize unlimited
extension/distance.
HDMI IN
HDMI EXTENDER
TX (Sender)
HDMI EXTENDER
RX (Receiver)
HDMI OUT
CAT5/5E/6
Cable
TV
Switch*N
Switch
HDMI EXTENDER
TX (Sender)
CAT5/5E/6 Cable
DVD
HDMI IN
HDMI OUT
HDMI EXTENDER
RX (Receiver)
TV
