2.3 One-to-many Connection:
By using network switch/router, one sender to several receivers (up 253
receiver units)
DVD
HDMI
IN
TV
TV
TV
HDMI OUT
HDMI OUT
HDMI OUT
CAT5/5E/6
Cable
CAT5/5E/6 Cable
HDMI EXTENDER
TX (Sender)
Switch
HDMI EXTENDER
RX (Receiver)
HDMI EXTENDER
RX (Receiver)
HDMI EXTENDER
RX (Receiver)
