7. Place all connectors inside
the unit and secure the cable
clamp to unit, making sure that
the cable clamp grips only the
jacket of service cable.
WARNING: Ensure the power
wiring is not installed so that it
is pinched or against a sharp
edge and ensure that the power
wiring is stored or secured to
avoid tripping or snagging to
reduce the risk of re, electric
shock or injury to persons.
8. Install the unit into the roughed
in framing ensuring that the unit
is resting on two framing sills,
one at the front and one at the
back or a level surface. Ensure
an air opening is maintained.
9. Level the housing - right to left
and front to back, using the
adjustable feet on the bottom of
the unit.
10. Secure the unit to the
permanent framing on either
end through a minimum of two
holes (Figure 4).
Operation Preparation
1. After the surrounding area has
been dry walled and nished,
remove the media plate from
the unit.
2. Unwrap the tethered controller
and ensure that the wire is
lead through the opening in
Installation
the bottom of the unit where
the hard plumbing attaches.
(Figure 4)
3. Locate the tethered controller
so that:
a) it can be easily accessed, if
being used as the main controls,
or
b) it is not obscured by either
bricks, stone or sheet metal so
that the signal that is sent from
the remote control can be easily
picked up.
4. Initialize the tethered controller
to the remote (see operation
section, page 16).
5. Fill the unit:
• Rell Containers - remove
the ll cap assemblies from
the inlet to the reservoir tanks,
then install the rell containers.
(Figure 10, page 18)
!
NOTE: During initial
installation, the Rell Container
should be relled after the
Reservoir has lled to ensure
the maximum operating time.
Rell Container holds 42 oz.
(1.25L).
• Hard Plumbed - prime each of
the water reservoirs with 33.5 oz
(1L) of water.
!
NOTE: Normal tap water can
be used in the Opti-myst
®
as long
as the tap water is not considered
