Dimplex 6909660400 - Maintenance; Filling the Water Tank; Transducer Replacement

17
WARNING: Disconnect
power before attempting any
maintenance or cleaning to
reduce the risk of re, electric
shock or damage to persons.
Filling the water tank
When the water tank is empty,
the ame effect will shut OFF and
the LED's will blink continuously.
Follow these steps to rel the
tank.
CAUTION: Allow at least ve
minutes for components to cool
before disassembling the unit to
rell.
1. Gently remove the media and
place it carefully on the ground.
2. Turn the On/Off switch to the
OFF position (O) (Figure 7A)
3. Remove the rell container by
lifting upwards and outwards.
4. Rell the container with tap
water.
!
NOTE: Normal tap water can
be used in the Opti-myst
®
as long
as the tap water is not considered
to be hard water. In the event
your tap water is hard, you may
use softened water or distilled
water with ⅛ tsp. of salt (0.5 mL)
added to the water reservoir. (The
use of additional salt should only
be when you notice that the unit is
not producing mist as expected.)
5. Screw the cap back on, do not
overtighten.
6. Return the rell container to the
sump, with the tank cap facing
down and the at side of the
tank facing outward.
7. Turn the On/Off switch to the
ON position ( I ). (Figure 7A)
8. Gently place the top tray back
into position.
If you do not intend on using
the unit for longer than 2 weeks,
empty and drain the unit of water,
and dry all of the water containing
components.
Transducer Replacement
After prolonged usage the ability
for the unit to produce mist may
become reduced. When this
occurs the replacement of the
transducer may be required.
This unit comes with additional
transducer(s), located within the
unit, which can be installed when
this occurs.
!
NOTE: There is a small tab
that holds the transducer in place,
that needs to be released before
it can be removed.
Maintenance
