15
C. Bluetooth
Required for initializing the remote
together with the Cassette, see
initialization instructions for more
detail.
D. Test Mode
Used for troubleshooting issues
- outlined in detail in the service
manual which can be found on
www.dimplex.com/customer_
support.
E. Flame Intensity Control
Adjusts the intensity of the ame
and smoke effect when the unit has
been activated.
Pressing the will decrease the
ame effect and pressing the
will
increase the ame effect.
!
NOTE: A few moments will be
required between adjustment and a
change to the ame effect.
!
NOTE: During normal
operation it is expected to see
some condensation of water on
the media plate. This will vary
depending on ambient conditions
and should be considered normal.
!
NOTE: When the water tank is
empty, the ame effect shuts OFF
and the LED's will blink twice,
continuously.
!
NOTE: On the CDFI1000-
PRO, each side of the ame can
be adjusted using the on-board
controls.
F. Volume Control
Adjusts the volume of the wood re
sound effects.
On the unit: Pressing the
will decrease the volume and
pressing the will increase the
volume.
On the Remote and Tethered
Controls: Pressing the will
turn the volume ‘ON’ ( I ) and
‘OFF’ ( O ).
G. Heat On/Off
Turns the optional heater
accessory ‘ON’ or ‘OFF’ .
!
NOTE: The 2 pin heater wire
(Figure 1) must be connected to
the heater for this control to work.
Remote Control
The tethered controller can be used
in the same manner as the remote
but houses the blue tooth receiver
for communication with the remote.
The tethered controller must be
connected to the unit and On/Off
Switch must be in the ‘ON’ ( I )
position in order for the remote to
operate.
Operation
