Dimplex BF36 Series User Manual

6
Replacement Parts List
CATALOGUE NO. BF36E BF36ST/HBI36ST BF36DX/HBI36DX
PART NO. 6900640459 6900640559 6900640659
MOD. LEVEL MOD 0-B MOD C,D MOD E 0-B MOD C,D MOD E
1 Log Set 0438200300RP 0438550200RP 0438200300RP 0438550200RP
2 Partially Reective Glass 5900160100RP 5900160600RP Not Available 5900160600RP 5900160700RP
3 Main On/Off Switch 2800070400RP
4 Heater On/Off Switch 2800070200RP 2800070500RP
5 Lower Light Harness 2500130100RP
6 Flicker Motor 6900360100RP 6900360600RP 6900360100RP 6900360600RP
7 Flicker Rod 6900190500RP
8 Blower Assembly N/A
5300160100RP
Send 0438650100RP also
N/A
5300160100RP
Send 0438650100RP also
9 Remote Control N/A 3000370600RP
10 Remote Control Receiver N/A 3000820500RP Send 8501580100RP also
11 Heating Element 2200460100RP
12 Cutout 2300200100RP 2300200800RP 2300200100RP 2300200800RP
13 Mesh Curtain 8800240103RP
14 Voltage Selector Switch N/A N/A Not Available N/A Not Available
15 Thermostat TS521W
CATALOGUE NO. BF42ST BF42DX/HBI42DX
PART NO. 6900640759 6900640859
MOD. LEVEL 0-B 0-B MOD C,D MOD E
1 Log Set 0438200300RP 0438550200RP
2 Partially Reective Glass 5900160200RP 5900160400RP
3 Main On/Off Switch 2800070400RP
4 Heater On/Off Switch 2800070500RP
5 Lower Light Harness 2500130100RP
6 Flicker Motor 6900360100RP 6900360600RP
7 Flicker Rod 6900190500RP
8 Blower Assembly
N/A
5300110300RP
Send 0438650100RP also
9 Remote Control 3000370600RP
10 Remote Control Receiver 3000820500RP Send 8501580100RP also
11 Heating Element 2200460100RP
12 Cutout 2300200100RP 2300200800RP
13 Mesh Curtain 8800240203RP 8800240103RP
14 Voltage Selector Switch N/A N/A Not Available
15 Thermostat TS521W
