3
Remote Control
The replace is supplied with a radio frequency remote
control. This remote control has a range of approximately
50 feet (15.25 m), it does not have to be pointed at the
replace and can pass through most obstacles (including
walls). It is supplied with one of hundreds of independent
frequencies to prevent interference with other units.
!
NOTE: Before attempting any operation with the
remote, pull the plastic insulator strip out from between
the remote casing and battery cover (Figure 2).
To operate, push the ON button to turn replace on, push
the OFF button to turn the replace off.
!
NOTE: Ensure that the replace Main ON/OFF
switch is set to the remote control setting.
Remote Control Initialization/Reprogramming
If the hand held transmitter or receiver board has been
replaced, follow these steps to initialize the transmitter and
receiver:
Place the 1. Main ON/OFF Switch (Figure 1A) in the OFF
(“O”) position.
Wait a minimum of ve (5) seconds and then place 2.
the Main ON/OFF Switch in the Remote Control
position.
Within3. 10 seconds of changing the switch position,
press the ON button located on the remote control
transmitter (Figure 2).
This will synchronize the remote control transmitter and the
replace receiver.
!
NOTE: You will have only 10 seconds to perform this
last step. Failure to do so will result in these steps
needing to be followed again.
Battery Replacement
To replace the battery:
Slide battery cover open on the hand held transmitter 1.
(Figure 2).
Install one (1) 12-Volt (A23) battery in the battery 2.
holder.
Close the battery cover3.
Battery must be recycled or disposed of properly.
Check with your Local Authority or Retailer for
recycling advice in your area.
OPERATION
To access the controls, swing down the front cover panel
located on the lower front of the replace. (Figure 1)
A. Main ON/OFF Switch
The switch has two ON positions marked with and
“Manual”. The “Manual“ position is for manual operation.
In this position the built-in remote control is by-passed.
The position is for operating the unit with the provided
remote control.
When in position the unit is operated with the ON and
OFF buttons of the remote control. When the switch is in
the center position the unit is off.
B. Heater ON/OFF Switch
The Heater ON/OFF Switch supplies power to the heater
fan and the heater element. When the switch is in the ON
position the heater operates if the thermostat calls for heat.
C. Heater Thermostat Control
To adjust the temperature to your individual requirements,
turn the thermostat control clockwise all the way to turn
on the heater. When the room reaches the desired
temperature, turn the thermostat knob counter clockwise
until you hear a click. Leave in this position to maintain the
room temperature at this setting. For additional heat, turn
clockwise until you hear the click again and the heater will
turn on.
Resetting The Temperature Cutoff Switch
Should the heater overheat, an automatic cut out will turn
the heater off and it will not come back on without being
reset. It can be reset by switching the Main ON/OFF
Switch to OFF and waiting 5 minutes before switching the
unit back on.
CAUTION: If you need to continuously reset the heater,
unplug the unit and call technical support at 1-888-346-
7539.
!
NOTE: The heater may emit a slight, harmless odor
when rst used. This odor is a normal condition caused
by initial heating of internal heater parts and will not occur
again.
Figure 2
Off Button
On
Button
Battery
Cover
Plastic
Strip
Figure 1
