Dimplex DF203A User Manual

6 www.dimplex.com
MODEL/CAT.
#
20” Compact
20”
Compact
20”
Compact
20”
Compact
DF2006
20”
Compact
DF2006 DF203A
PART NO. 6901860100 6901860200 6901860300 6901860400 6901860500 6901860600 6901860700 6901860800
MOD LEVEL: NONE NONE NONE NONE NONE NONE NONE NONE
PART PART NUMBER
1. Logset 0438270100RP 0478550100RP
2. Flicker
Motor
2000220100RP
3. Heater
Assembly
2200490800RP
4. Cutout 2300270100RP
5. Thermostat 2300150100RP*
6. Heat On/Off
Switch
2800070200RP
7. Capacitor 3200030100RP
8. Terminal
Block
4000070100RP
9. Cord Set 4100090104RP
10. Reector
Assembly
5900340100RP
11. Mirror 5900410100RP 5900560100RP 5900620100RP
12. Front Glass 5900420100RP
13. Bushing,
Snap In
8500000400RP
14. Flicker
Connector
8500680100RP
15. Control
Knob
8800000300RP
16. Lamp
holder
Assembly
4200120800RP 2500170100RP 2500170300RP
17. Heyco
Strain Relief
8500260003RP
18. Main
Power Switch
2800070200RP 2800071100RP
19. Remote
Receiver
(Built-in)
N/A 3000380200RP
20. Remote
Transmitter
N/A 3000370500RP
REPLACEMENT PARTS
