3
Remote Control
control. This remote control has a range of approximately
50 feet (15.25 m), it does not have to be pointed at the
walls). It is supplied with one of hundreds of independent
frequencies to prevent interference with other units.
!
NOTE:
remote, pull the plastic insulator strip out from between
!
NOTE
set to the remote control setting.
Remote Control Initialization/Reprogramming
If the hand held transmitter or receiver board has been
replaced, follow these steps to initialize the transmitter and
receiver:
Place the 1.
(“O”) position.
2.
II”).
Within3. 10 seconds of changing the switch position,
press the ON button located on the remote control
This will synchronize the remote control and the remote
control receiver.
!
NOTE: You will have only 10 seconds to perform this
needing to be followed again.
Battery Replacement
To replace the battery:
1.
2).
Install one (1) 12-Volt (A23) battery in the battery 2.
holder.
Close the battery cover3.
Check with your Local Authority or Retailer for
recycling advice in your area.
OPERATION
The power switch has two (2) On positions marked with “ I
” and “ II ”. The “ I ” position is for manual operation. In this
position the built-in remote control is bypassed.
The “ II ” position is for operating the unit with the provided
remote control. When in “ II ” position the unit is operated
When the switch is in the center (“ O ”) position the unit is
off.
heater element. When the switch is in the On position the
heater operates if the thermostat calls for heat.
To adjust the temperature to your individual requirements,
turn the thermostat control clockwise all the way to turn
on the heater. When the room reaches the desired
temperature, turn the thermostat knob counter clockwise
until you hear a click. Leave in this position to maintain the
clockwise until you hear the click again and the heater will
turn on.
The heating assembly is protected with a safety device
overheat, an automatic cut out will turn the heater off and it
will not come back on without being reset. It can be reset
(5) minutes before switching the unit back on.
CAUTION: If the unit continuously cuts out, unplug the
unit and call customer service at 1-800-DIMPLEX.
!
NOTE: The heating elements may emit a slight,
condition caused by initial heating of internal heater parts
and will not occur again.
Figure 2
On
Cover
Plastic
Figure 1
A
B
C
