2 www.dimplex.com
Always use a qualied technician or service agency to repair this replace.
!
NOTE: Procedures and techniques that are considered important enough to emphasize.
CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the
equipment.
WARNING: Procedures and techniques which, if not carefully followed, will expose the user to the
risk of re, serious injury, or death.
OPERATION .........................................................3
MAINTENANCE ......................................................4
EXPLODED PARTS DIAGRAM ..........................................5
REPLACEMENT PARTS ...............................................5
WIRING DIAGRAM ...................................................6
SWITCHBOARD REPLACEMENT ........................................7
RELAY BOARD REPLACEMENT ........................................7
AC/DC ADAPTER REPLACEMENT ......................................8
DISPLAY/CONTROL BOARD REPLACEMENT .............................8
HEATER ASSEMBLY REPLACEMENT ....................................8
POWER CORD REPLACEMENT .........................................9
FLICKER MOTOR & FLICKER ROD REPLACEMENT ........................9
LED LIGHT ASSEMBLY REPLACEMENT .................................10
LOG SET ASSEMBLY REPLACEMENT ..................................10
PARTIALLY REFLECTIVE PANEL REPLACEMENT ........................10
THERMISTOR REPLACEMENT ........................................11
TROUBLESHOOTING GUIDE ..........................................12
TABLE OF CONTENTS
