CAUTION
Clearance for air circulation beneath the fi replace insert is provided by two rubber feet.
DO NOT INSTALL THE FIREPLACE INSERT DIRECTLY ON CARPET OR SIMILAR SURFACES WHICH
MAY RESTRICT AIR CIRCULATION. If installing the fi replace in a carpeted area, place a one-piece,
solid, fl at surface under the fi replace insert. Ensure that both of the insert’s feet rest securely on this
surface.
OPERATION
ELECTRIC FIREPLACE MANUAL CONTROL
The manual controls for the fi replace are located in the lower right hand corner. (FIGURE 5)
A. Main On/Off Switch
Supplies power to the 3 position manual control switch.
B. 3 Position Manual Control Switch
Remote (right position): The unit is operated with the remote control.
Flame (center position): The fl ame effect is turned ON.
Flame & Heat (left position): The fl ame effect and heater are turned ON simultaneously. When
the manual control is in the Flame & Heat position the heater does not run on the remote oper
ated thermostat.
NOTE
When the manual control switch is in the Flame and Flame & Heat positions, the fi replace unit
will not operate with the remote control.
C. Initialization Button
Used to synchronize the remote control.
A. Main On/Off Switch
B. 3 Postion Manual Control
C. Initialization Button
FIGURE 5
RESETTING THE TEMPERATURE CUTOFF SWITCH
Should the heater overheat, an automatic switch will turn the heater off and it will not come back on
without being reset. The temperature cutoff switch can be reset by unplugging the unit, waiting 5 minutes
and plugging the unit back in.
CAUTION
If you need to continuously reset the heater, unplug the unit and call Dimplex North America Limited at
1-888-346-7539 and press 4 for technical support. Please have your model and serial number ready
when calling.
