6 www.dimplex.com
WIRING DIAGRAM
Switch
Lamp
Flicker
Motor
Cord
Blower
Motor
Element
Cutout
Lamp
Terminal
Block
Thermostat
Wide blade (N)
Wire of wide
blade of plug
Narrow Blade (L)
Capacitor
Switch
RECEIVER,
REMOTE CONTROL
With Integral Remote Control Receiver and Thermostat
With External Remote Control Receiver and Thermostat
