Dimplex EF3003 Service Manual

8 www.dimplex.com
Part
Canada China
EF3003/
SF3003
Mod 0
EF3003/
SF3003
Mod A
EF3003/SF3003/DF3003 DFB6016
Mod 0 Mod A Mod B Mod C Mod D Mod E Mod 0 Mod A Mod B Mod C Mod D
1 Log Set 0438550100RP
2 Grille Assembly 1009070159RP
3 Heater Assembly NA 2000230100RP 2200490901RP comes with cutout 2300270300RP
4
Upper Light
Harness (2-bulb)
2500080100RP
5
Upper Light
Harness (Single)
4200121000RP (2 Required)
6
Lower Light
Harness (4-bulb)
2500190500RP
(comes with connectors,
strip the ends)
2500190500RP
7 On/Off Switch 2800070200RP
8
Heater On/Off
Switch
2800070500RP
9
LED & Switch
Remote
Harness
3000210400RP (Acumen)
10
Remote Control
Receiver
3000210100RP (Acumen)
3000430800RP
(3 STAGE)
3000820500RP
(3 STAGE)
3000430800RP
(3 STAGE)
3000820500RP
(3 STAGE)
11 Remote Control 3000211300RP (Acumen) 3000370600RP (3 Stage, LED’s wired to Board)
12 Dimmer Knob 8800000800RP 8800000200RP
13 Dimmer Control
Not Available - Can use
single pole wall dimmer
i.e. Leviton 6602-I
3000250100RP (Circuit Board and Potentiometer)
14
Flame Control
Knob
8800000200RP
15 Flicker Motor 2000150200RP 3000240200KIT
16
Flame Speed
Control
3000180300RP
(Potentiometer Only)
3000240100RP (Circuit Board and Potentiometer)
17 Power Cord 4100040400RP 4100040500RP
18
Partially Reec-
tive Glass
5900300200RP 5900300300RP 5900300400RP
19 Front Glass 5900310200RP
20 Flame Panel 5900320100RP
21
Decal, Side
Brick
7108890200RP
22 Bushing Snap-In 8500000400RP
23
Rotisserie
Grommet
8500000600RP
24 Grommet 8500260003RP
25
Flicker Rod
Assembly
5900080700RP
26 Firebox Foot 8800090100RP
27 DFB Trim Kit 6903430159RP
Replacement Parts List

Dimplex EF3003 Specifications

General

Brand	Dimplex
Model	EF3003
Category	Indoor Fireplace
Language	English
