Dimplex SS5800PB Service Manual

6
Replacement Parts List
DS5598, SS5800PB, SS5858N
CATALOGUE NO.
PART NO.
MOD. LEVEL
MADE IN:
DS5598 SS5800PB SS5858N DS5598
6900330100 6900330100
6900330100
6900330400
6900610100 6900610200 6900330700 6900330800
NONE MOD A & B MOD. C MOD B MOD NONE MOD. D MOD. E
CANADA CANADA CANADA CANADA CANADA CANADA CHINA
1 Front Glass 5900110100RP
2 Log Set Assembly 0438270100RP
3 Front Panel Not Available
4 Partially Reective Glass 5900060400RP
5 Minix Bolt Not Available
6 Left Side Gable Not Available
7 Top Panel Not Available
8 Flicker Rod Not Available
9 Flicker Motor 2000140100RP 2000210100RP
10 Right Side Gable Not Available
11 Thermostat 2300150100RP
12 On/Off Switch 2800070100RP (Neon) 2800070200RP
13 Thermostat Knob 8800000300RP
14 Heater Assembly Not Available 6902410100RP (send 7206910100R01) 2200490700RP
15 Bottom Panel Not Available
16 Minix Bolt 8000380100RP
17 Heater On/Off Switch N/A 2800070200RP
18 Foot, Plastic 0438620159RP
19 Door Not Available 0438240159RP
20 Terminal Block 4000070100RP
21 Power Cord 4100040200RP
22 Lower Light Assembly 2500080100RP 4200120300RP
23 Upper Light Assembly 2500100100RP 4200120400RP
24 Remote Control & Receiver 680024RPNEW
DS5603, DS5804
CATALOGUE NO.
PART NO.
MOD. LEVEL
MADE IN:
DS5603 DS5804
6900330500 6900330600 6900330900 6900330900 6900331000
MOD. C MOD. D MOD. E MOD. G MOD. E MOD. G
CANADA CANADA CHINA CHINA CHINA CHINA
2 Log Set Assembly 0438270100RP
4 Partially Reective Glass 5900060400RP
8 Flicker Rod Not Available
9 Flicker Motor 2000140100RP 2000210100RP
11 Thermostat 2300150100RP
12 On/Off Switch 2800070200RP 2800071100RP 2800070200RP 2800071100RP
13 Thermostat Knob 8800000300RP
14 Heater Assembly
6902410100RP (send
7206910100R01)
2200490700RP
17 Heater On/Off Switch 2800070200RP
18 Foot, Plastic 0438620159RP
19 Door Not Available 0438600159RP Not Available
20 Terminal Block N/A 4000070100RP
21 Power Cord 4100040900RP
22 Lower Light Assembly 2500080100RP 4200120300RP
4200121000RP
4200120300RP 4200121000RP
23 Upper Light Assembly 2500100100RP 4200120400RP 4200120400RP
24 Remote Control
680024RPNEW
3000370500RP
680024RPNEW
3000370500RP
25 Remote Control Receiver 3000380200RP 3000380200RP
