Dimplex VCX1525 - Wall Mounting Instructions

8 www.dimplex.com
WARNING: The Convex
In Stud replace is wall
mountable and can be built in
a wall space 16 inches (406
mm) over-center between 2”
x 4” wall studs. Follow the
installation instructions for
either wall mount or built-in
mounting; failure to do so may
cause damage or injury.
Wall Mounting Instructions
Leave the glass assembly 1.
uninstalled until step 10.
Select a location for the 2.
replace, preferably above
an electrical outlet and there
must be at least one wall stud
behind for the replace to
mount onto. The bottom of
the unit must be a minimum
of 14" (356 mm) above the
oor (mounting holes 29¾"
(0.75 m) minimum above the
oor) (Figure 2).
Access to the electrical outlet
must be maintained. Ensure the
installation meets the national and
state/provincial electrical codes.
!
NOTE: It is recommended
that the bottom of the unit not be
mounted higher than 48" (1.22
m) from the ground to maintain
an optimized viewing angle of the
Fireplace Installation
ame.
CAUTION: The replace must
be mounted at two (2) points, one
of which must be on a wall stud.
WARNING: High tempera-
tures may be generated under
certain abnormal conditions. Do
not partially or fully cover or ob-
struct the bottom of this heater.
Bottom of unit must be a mini-
mum of 14" (356 mm) above the
oor or any surface such as a ta-
bletop to ensure adequate space
Figure 2
A
B C D E F G
H
29¾” - 75¾”
(0.75 - 1.92m)
14” - 48”
(0.36 - 1.22m)
