13. The third row of energy cells is positioned in a manner similar to the • rst row. Again
be careful not to damage or dislodge the element. (Fig. 13)
14. Fit the fourth row of energy cells above the third row in the upside position. Again,
• rst energy cell should be positioned • rmly against the right-hand insulation, and the
second energy cell should be positioned • rmly against the left-hand insulation. (Fig.
14)
Repeat for the • fth and sixth rows of energy cells built around the third element to
complete the core build.
15. Remember the top row of energy cells must be • tted upside down. (Fig. 15)
Check that all the energy cells are secure and evenly located.
16. Close the core by re• tting the inner front panel complete with insulation, starting
at position ‘U’ and working clockwise. (Fig. 16)
Ensure the bottom tabs are located inside the chassis and that the screws are tightly
secured down each edge.
Ensure the screws retaining the heater to the wall are fully tightened, once the
energy retention cells are fully loaded. (Fig. 6)
IMPORTANT
Double check all mains connections are secure and excess cable is restrained and not
in contact with any of the heater casing.
ON NO ACCOUNT SHOULD ANY SURPLUS CABLE BE PUSHED INSIDE OR
BEHIND THE HEATER.
Once installed DO NOT attempt to reposition the heater without ! rst unloading
the energy cells.
Reassembly
To replace the bottom grille and front panel, reverse steps 3 and 4 of these instructions
under the section headed Preparation.
Inspect the grille guard for damage before re• tting the lower grille to the heater.
Ensure all • xings are secure.
15
