DINA DNSL-ZM User Manual

Inputs for safety functions
Original instruction manual Date: 2017.08.28 Page 16 of 28
11 Inputs for safety functions
Modules Inputs
DNSL-ZM/ ZMA/ ZMK I1 I2 I3 I4 I5 I6
DNSL-ZMB/ ZMR/ ZMT I1 I2 I3 I4 I5 I6 I11 I12 I13 I14 I15 I16 I17 I18 I19 I20
DNSL-DS / DR / SI B11
B12
B13
B14
B21
B22
B23
B24
DNSL-IN I11 I12 I13 I14 I15 I16 I17 I18 I21 I22 I23 I24 I25 I26 I27 I28
DNSL-IO/ DNSL-FB I21 I22 I23 I24 I25 I26 I27 I28
DNSL-IO2 I15 I16 I17 I18 I21 I22 I23 I24 I25 I26 I27 I28
11.1 Safe Shutdown mat functions using I16 – I20 at DNSL-ZMT
Up to eight shutdown mats can be monitored.
After stepping on the mat the quit-function in the Designer can be
activated.
The configuration will be done with the Designer.
Input value < min value: SM
Input value > min < max value: SM
Input value > max value: SM
Designer Symbol Quit Symbol
11.2 Input for function mode switch (FMSS) at the central module
Function mode
(
FM
)
FMSS
with 4
p
osition
s
FMSS
with 6
Position
s
3 Function modes
I1 I2 I3
2
4
5
6
1
24VDC
I2
I1
I3
I4
I5
I6
3
I2
I1
I3
1
2
3
2 3
I1
I2
1
Error
I4
4
I5
5
I6
6
FM1
FM2
FM3
6 Function modes
I1 I2 I3 I4 I5 I6
FM1
FM2
FM3
FM4
FM5
FM6
• Only one switching position has to be selected
• Error: None or more than one
11.3 Input for Tow-Hand functions according to EN 574: Type IIIC
Inputs Control Diagram Designer Symbol
Modules E1 Q1 E2 Q2
Q1 E1 Q2E2
Q2
E1
E2
2H
Q1
>500ms
Q2
OK
<500ms
DNSL-ZM/ ZMA I1 I2 I3 I4
DNSL-ZMK/ ZMB I1 I2 I3 I4
DNSL-ZMR/ ZMT I1 I2 I3 I4
DNSL-DS / DR B11
B12
B13
B14
DNSL-IN I11 I12 I13
I14
DNSL-IO/ IO2 I21
I22
I23
I24
Start keys have to be activated during 500ms
1 2
3
24VDC
I1
I2
I3
4
I4
I2
I1
I3
1
2
3
2 3
I1
I2
1
Error
