DINGLI JCPT2223RT - Page 68

OPERATOR’S MANUAL with Maintenance Information
Maintenance
63
Display
for
Platform
Display for Ground
Description
Repair
38
38 LF OR Limit Switch Fault
Left Front Outrigger Limit
Switches are both ON
Check the limit switch,
check the wiring
39
39 RF OR Limit Switch Fault
Right Front Outrigger Limit
Switches are both ON
Check the limit switch,
check the wiring
40
40 LR OR Limit Switch Fault
Left Rear Outrigger Limit
Switches are both ON
Check the limit switch,
check the wiring
41
41 RR OR Limit Switch Fault
Right Rear Outrigger Limit
Switches are both ON
Check the limit switch,
check the wiring
49
49 Drive Coil 1 Fault
Power FET, channel DRIVE 1
fails
check the wiring,
replace the valve
50
50 Drive Coil 2 Fault
Power FET, channel DRIVE 2
fails
check the wiring,
replace the valve
51
51 Drive Coil 3 Fault
Power FET, channel DRIVE 3
fails
check the wiring,
replace the valve
52
52 Func Prop Coil Fault
power FET, channel
PROPORTIONAL 1 fails
check the wiring,
replace the valve
54
54 Up Coil Fault
Power FET, channel DOWN
fails
check the wiring,
replace the valve
55
55 Down Coil Fault
Power FET, channel RT fails
check the wiring,
replace the valve
56
56 Right Turn Coil Fault
Power FET, channel LT fails
check the wiring,
replace the valve
57
57 Left Turn Coil Fault
Power FET, channel LT fails
check the wiring,
replace the valve
58
58 Brake Coil Fault
Power FET, channel LT fails
check the wiring,
replace the valve
60
60 Forward 1 Coil Fault
Power FET, channel FORWARD
LEFT fails
check the wiring,
replace the valve
61
61 Reverse 1 Coil Fault
Power FET, channel REVERSE
LEFT fails
check the wiring,
replace the valve
66
66 Low Oil Pressure
Oil Pressure Fault
check the wiring,
replace the sensor
67
67 High Cool ant
Temperature
Water Temperature Fault
check the wiring,
replace the sensor
68
68 Low ECU Voltage
Low Battery Voltage
check the wiring,
check the battery
69
69 Low Engine RPM
Low RPM Fault
check the wiring,
check the engine
70
70 High Engine RPM
High RPM Fault
check the wiring,
check the engine
81
81 Left Front Otrg Coil Flt
Power FET, channel LEFT
FRONT OUTRIGGER fails
check the wiring,
replace the valve
