OPERATOR’S MANUAL with Maintenance Information
Decals
9
Decal Inspection
Use the pictures on the next page to verify that all decals are legible and in place.
Below is a numerical list with quantities and descriptions.
No. Part No. Description Qty. Remark
1 09440011 Decal, Label-Lanyard anchorage point 4
2 09340001 Decal, Notice-Keep the manual with the machine 1
3 09440003 Decal, Danger-Tip-over hazard, tilt-alarm 1
4 09440001 Decal, Danger-General safety rules 1
5 09340003
Decal, Instructions-Refer the operator to the
instructions for use
2
6 09440070 Decal, Label-Capacity 230kg 1
7 09210015 Nameplate, Manufacturer serial number 1
8 09310001 Decal, Instructions-Forklift pockets 2
9 09310003 Decal, Instructions-Tie down point 4
10 09310002 Decal, Instructions-Lift point 4
11 09310061 Decal, Instructions-Maximum wheel load 670kg 4
12 09310064 Decal, Notice-Main power switch operation 1
13 09540001 Decal, Label-CE 3
14 09410001 Decal, Danger-Explosion/burn hazard 1
15 09430001 Decal, Danger-Safety arm 2
16 09430003 Decal, Danger-Keep away from moving parts 3
17
09640066 Decal, Cosmetic-S06-EH 2 S06-EH
09640067 Decal, Cosmetic-S06-E 2 S06-E
18 09440009
Decal, Caution-Max. manual force 400N (Indoor)
200N (Outdoor)
2
19
09940003 Decal, Label-E-Tech 2 S06-EH
09940004 Decal, Label-Summit 2 S06-E
20 09410005 Decal, Danger-Do not alter or disable limit switch 1
21 09310004 Decal, Instructions-Emergency lower 1
22 09410003 Decal, Warning-Inspected and operation properly 1
