OPERATOR’S MANUAL with Maintenance Information
Specifications
12
Model: S06-EH
Height, working maximum 7.8 m
Height, platform maximum 5.8 m
Height, stowed maximum
Rails up
2.15 m
Height, stowed maximum
Rails lowered
1.83 m
Width 0.76 m
Length, platform retracted 1.86 m
Length, platform extended 2.76 m
Platform dimensions
Platform length × width
1.67×0.74 m
Platform extension length 0.9 m
Maximum load capacity 230 kg
Maximum wind speed 12.5 m/s
Wheelbase 1.36 m
Turning radius (outside) 1.64 m
Turning radius (inside) 0 m
Ground clearance 7.2 cm
Ground clearance
Pothole guards deployed
1.6 cm
Weight
See Serial Label
Machine weights vary with option configurations
Power source 4 Batteries , 6V 210 Ah
Controls Proportional
AC outlet in platform Standard
Maximum hydraulic pressure
(functions)
180 bar
System voltage 24 V
Tire size Φ305×100 mm
Airborne noise emissions <70 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m/s
2
Maximum slope rating,
Stowed position
25%
Maximum side slope rating,
Stowed position
25%
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope X-1.5°,Y-3°
Drive speeds
Stowed, maximum 3.5 km/h
Platform raised, maximum 0.5 km/h
Floor loading information
Tire load, maximum 670 kg
Tire contact pressure 9.5 kg/cm
2
932.4 kPa
Occupied floor pressure 1305.6 kg/m
2
12.8 kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
ade
q
uate safet
y
factors.
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
