DINGLI S06-E - Schematic

OPERATOR’S MANUAL with Maintenance Information
Schematic
69
Hydraulic Schematic
For S06-EH
SV2
1mm
1mm
S1 S2
P
M
T
BRK
RV1
SV1
FR
RV4
CV2
RV3
CV1
1.1mm
SV4
SV3
D3
D2
D1
D4
L
P41
P42
CV1
1.5mm
Lower valve
NBCY-1001A-11
80bar
235bar
3.45bar
Tank
Pump
5802-4-12
Valve 5805-0116R
Hand pump
5805-0412(960020A10)
RV2
150bar
Platform loading
（ Option ）
Steer cylinder
Lift cylinder
