Location
Function
J1, J2
VOUT and Load Connector
J3
I2C Bus & other test pins
J4
DP, DN & other test pins
Table 2 – Jumpers and functions of the Evaluation Board
3.5 EVB System BOM
Item
Quantity
Reference
Description
Manufacturer
Part Number
Manufacturer
1
2
C1, C3
10μ/50V
-
-
2
6
C2, C4, C5, C7, C8,
C9
0.1μ/50V
-
-
3
1
C6
1μ/50V
-
-
4
8
R4, R8. R9, R12, R13,
R17, R18, R19
0R
-
-
5
1
R5
100R
-
-
6
1
R14
1K
-
-
7
2
R6, R7
4.7K
-
-
8
2
R10, R11
5.1K
-
-
9
2
R15, R16
10K
-
-
10
2
R2, R3
100K
-
-
11
1
R1
5mR/1W 1206
SMD12A1FR005T
SART Inc.
12
3
D1, D2, D7
LED
-
-
13
2
Q1, Q2
30V/45A/4.4mΩ N-CH
PowerDI3333-8
DMN3009SFG
Diodes
Incorporated
14
1
U1
USB PD3.1 Sink Controller With I²C
AP33772S QFN-24
Diodes
Incorporated
15
1
U4
Reserved EEPROM solder location
N/A
N/A
16
1
CON1
USB Type-C Receptacle
-
-
17
2
J1, J2
VOUT & GND
-
-
18
2
J3, J4
DP, DN, I²C, & other test pins
-
-
19
4
D3~D6
Zener Diode (option)
N/A
N/A
Table 3 – BOM list of the AP33772S EVB’s schematics
