PINK/WHITE (+) Output to Second Ignition Circuit
Connect this wire to the second ignition wire in the vehicle.
NOTE: For vehicles that do not have a second ignition wire, this connection is not required.
Remote Start Ribbon Harness Wiring Diagram
___
___
___
___
___
Remote Start Harness (H3),
Wire Connection Guide
Remote Start Harness (H3) Wiring Diagram
___
___
___
___
___
___
Remote Start Harness Wire Descriptions
H3/1 BLUE Status Output
This wire supplies a 200mA output as soon as the module begins the remote start process. The H3/1
BLUE wire can also be used to rearm a factory anti-theft system when the remote start shuts down.
(See the Feature Descriptions section in this guide.)
NOTE: This wire can also be used to bypass optional sensors as described in the following diagram.
BLACK/WHITE (-) Nuetral Safety Switch Input
VIOLET/WHITE Tachometer Input Wire
BROWN (+) Brake Switch Shutdown Wire
GRAY (-) Hood Pinswitch Shutdown Wire
BLUE/BLACK (-) 200 mA Optional Third Ignition Output
BLUE (-) Status/Factory Security Rearm Output
1
2
3
4
5
6
RED (+) Constant Power
YELLOW (+) Ignition Input to Remote Start
PINK (-) 200 mA Ignition Relay Turn-On
ORANGE (-) 200 mA Accessory Relay Turn-On
PURPLE (-) 200 mA Starter Relay Turn-On
1
2
3
4
5
