Wiring Quic
k Reference Guide
41
Table of Contents
Table of Contents
3
Before Beginning the Installation
5
Finding the Tachometer Wire
5
M M U U L L T T I I - - L L E E V V E E L L S S E E C C U U R R I I T T y y a a R R M M I I N N G
5
N N U U I I S S a a N N C C E E P P R R E E V V E E N N T T I I O O N N ® ® C C I I R R C C U U I I T T R R y
5
Finding the WAIT-TO-START Bulb Wire for Diesels
6
After the Installation
6
Vehicle Anti-Theft Systems (Immobilizers)
6
Primary Harness (H1) Wiring Diagram.7
7
Primary Harness Wire Descriptions
7
H1/2 White
8
H1/3
9
H1/4 Black/White
9
H1/5 Green
9
H1/6
10
H1/7 Violet
10
H1/8
10
H1/10
11
H1/11
11
H1/12
11
Secondary Harness (H2) Wiring Diagram
12
Secondary Harness Wire Descriptions
12
Heavy Gauge Relay Satellite Wiring Diagram
14
Heavy Gauge Relay Satellite Wire Descriptions
14
Remote Start Ribbon Harness Wiring Diagram
15
Remote Start Harness (H3) Wiring Diagram
15
Remote Start Harness Wire Descriptions
15
Testing the Neutral Safety Switch
18
Super Bright LED, 2-Pin WHITE Plug
19
Valet/Program Switch, 2-Pin BLUE Plug
20
Programmer Interface, 3-Pin Port
20
Shock Sensor Harness, 4-Pin Connector
20
Mounting the Receiver/Antenna
21
Light Flash Jumper
22
Tach Threshold On/Off
22
Menu #1 - Basic Features
25
Menu #2 - Advanced Features
25
Menu #3 - Remote Start Features
26
Menu #1 - Basic Features
26
Menu #2 - Advanced Features
28
Menu #3 - Renote Start Features
29
Standard Configuration
32
Single Button Arm/Disarm Configuration
33
Arm/Disarm Diagnostics
36
System Status Chirps
36
Table of Zones
36
Alarm Troubleshooting
39
Remote Start Troubleshooting
40
