© 2000 Directed Electronics, Inc. Vista, CA 39
feature menus
The default settings are indicated in bold type. Features that have additional settings that can be programmed
using the Bitwriter are indicated with an asterisk (*).
FEATURE NUMBER ONE-CHIRP SETTING (DEFAULT) TWO-CHIRP SETTING
2-1 Siren output constant Siren output pulsed
2-2 30 second siren duration* 60 second siren duration*
2-3 Nuisance Prevention Circuitry on Nuisance Prevention Circuitry OFF
2-4 Progressive door trigger Instant door trigger
2-5 Disarm from Valet, 1 pulse Disarm from Valet, 2-5 pulses
2-6 Door sensor bypass chirp on Door sensor bypass chirp OFF
2-7 Ignition controlled domelight on Ignition controlled domelight OFF
2-8 Single unlock pulse Double unlock pulse
2-9 Factory disarm with Channel Two on Factory disarm with Channel Two OFF
2-10 Channel Four validity Channel Four: latched/latched, reset
with ignition/30-second timed/
second unlock output
menu #2 - advanced features
FEATURE NUMBER ONE-CHIRP SETTING (DEFAULT) TWO-CHIRP SETTING
1-1 Active arming Passive arming
1-2 Arm/disarm chirps on Arm/disarm chirps off
1-3 Ignition-controlled door locks* Standard door locks*
1-4 Active locking only Passive locking
1-5 Panic with ignition on No panic with ignition on
1-6 0.8 second door lock pulses 3.5 second door lock pulses
1-7 Forced passive arming on Forced passive arming off
1-8 Automatic engine disable on Automatic engine disable off
1-9 Armed When Driving (AWD) on AWD off
1-10 Code Hopping on Code Hopping off
menu #1 - basic features
