© 2000 Directed Electronics, Inc. Vista, CA 7
primary harness (H1), 12-pin connector
______
______
______
______
______
______
______
______
______
______
______
______
secondary harness (H2), 3-pin connector
______
______
______
VIOLET/BLACK (-) SELECTABLE CHANNEL 4 OUTPUT
LIGHT GREEN/BLACK (-) FACTORY DISARM/SPECIAL ACCESSORY OUTPUT
GRAY/BLACK (-) WAIT-TO-START INPUT
H2/1
H2/2
H2/3
RED/WHITE (-) 200 mA CHANNEL 2 VALIDITY OUTPUT
RED (+) CONSTANT POWER INPUT
BROWN (+) SIREN OUTPUT
OPEN NO WIRE
BLACK (-) CHASSIS GROUND INPUT
VIOLET (+) DOOR TRIGGER INPUT, ZONE 3
BLUE (-) MULTIPLEXED INPUT, ZONE 4
GREEN (-) DOOR TRIGGER INPUT, ZONE 3
BLACK/WHITE (-) 200 mA DOMELIGHT SUPERVISION OUTPUT
WHITE/BLUE (-) REMOTE START ACTIVATION INPUT
WHITE (+)/(-) SELECTABLE LIGHT FLASH OUTPUT
ORANGE (-) 500 mA ARMED OUTPUT
H1/1
H1/2
H1/3
H1/4
H1/5
H1/6
H1/7
H1/8
H1/9
H1/10
H1/11
H1/12
