Programming System Features
The System Features Learn Routine dictates how the unit operates. It is possible to access and change most of
the feature settings using the Control button.
Open1. a door.
Turn2. the ignition on, then off.
Select3. a Menu. Press and hold the Control button. The number of siren chirps indicates the menu num-
ber. 1 chirp indicates menu 1, 2 chirps - menu 2 and 3 chirps for menu 3.
When the desired menu chirps are heard, 4. release the Control button.
Select5. a Feature. Press and release the Control button the number of times corresponding to the feature
you wish to change. Then press and hold one more time to select the features.
Program6. the Feature. While holding the Control button, you can program the feature using the remote
control.
For features with only two options;
= option 1 while = option 2.
For features with more than two options;
selects the options in ascending order, while selects them in
descending order.
Note:
Pressing
button resets the feature to the factory default.
Once a feature is programmed:
Other features can be programmed within the same menu
Another menu can be selected
The learn routine can be exited if programming is complete
To access another feature in the same menu:
Press1. and release the Control button the number of times necessary to advance from the feature you just
programmed to the next one you want to program.
Then 2. press the Control button once more and hold it.
To select another menu:
Press1. and hold the Control button.
After 3 seconds, the unit advances to the next menu and the siren chirps, indicating which menu has been 2.
accessed.
The learn routine exits if any of the following occurs:
The open door is closed
The ignition is turned On
There is no activity for 30 seconds
The Control button is pressed too many times
