6
© 2009 Directed Electronics. All rights reserved.
Wiring Connections
Main Harness (H1), 12-pin connector
H1/1
RED/WHITE (-) 200mA AUX/TRUNK OUTPUT
H1/2 RED (+)12VDC CONSTANT INPUT
H1/3 BROWN (+) SIREN OUTPUT
H1/4 WHITE/BROWN PARKING LIGHT ISOLATION WIRE - PIN 87a of onboard relay
H1/5 BLACK (-) CHASSIS GROUND
H1/6 VIOLET (+) DOOR TRIGGER INPUT
H1/7
BLUE (-) TRUNK PIN/ INSTANT TRIGGER INPUT (N/C OR N/O)
H1/8 GREEN (-) DOOR TRIGGER INPUT (N/C* OR N/O)
H1/9 BLACK/WHITE (-) 200mA DOME LIGHT SUPERVISION OUTPUT
H1/10 WHITE/BLUE (-) REMOTE START/ TURBO TIMER ACTIVATION INPUT
H1/11 WHITE PARKING LIGHT OUTPUT
H1/12
ORANGE (-) 500mA GROUND WHEN ARMED OUTPUT
*The Normally Closed setting will only work if one of the vehicle's doors is connected. If more than one door
is to be monitored, then it is recommended to use the Xpresskit DTIMAZDA or tech tip # 1921 on www.direct-
echs.com to interface with these types of vehicles.
H2 Harness, 18-pin connector
H2/1
LIGHT GREEN/BLACK (-) 200mA OEM ALARM DISARM OUTPUT
H2/2 ORANGE/BLACK (-) 200mA AUX 4 OUTPUT
H2/3 GREEN/WHITE (-) 200mA OEM ALARM ARM OUTPUT
H2/4 VIOLET/BLACK (-) 200mA AUX 2 OUTPUT
H2/5 WHITE/BLACK (-) 200mA AUX 3 OUTPUT
H2/6 WHITE/VIOLET (-) 200mA AUX 1 OUTPUT
H2/7 GREY/BLACK (-) DIESEL WAIT TO START INPUT
H2/8 BROWN/BLACK (-) 200mA HORN HONK OUTPUT
H2/9 VIOLET/WHITE TACHOMETER INPUT
H2/10 DARK BLUE (-) 200mA STATUS OUTPUT
H2/11 PINK/WHITE (-) 200mA FLEX RELAY CONTROL OUTPUT
H2/12 ORANGE (-) 200mA ACCESSORY OUTPUT
H2/13 PURPLE (-) 200mA STARTER OUTPUT
H2/14 PINK (-) 200mA IGNITION 1 OUTPUT
H2/15 GREY (-) HOOD PIN INPUT (N/C OR N/O)
H2/16 BLUE/WHITE (-) 200mA 2ND STATUS /REAR DEFOGGER OUTPUT
H2/17 BROWN (+) BRAKE SHUTDOWN INPUT
H2/18 BLACK/WHITE (-) NEUTRAL SAFETY INPUT
Remote Start, (H3) 10-pin connector
H3/1 PINK (+) IGNITION 1 INPUT/OUTPUT
H3/2
RED/WHITE (87) FLEX RELAY +12V INPUT (30A FUSED)
H3/3 ORANGE (+) ACCESSORY OUTPUT
H3/4 VIOLET (+) STARTER OUTPUT (CAR SIDE OF THE STARTER KILL)
H3/5 GREEN (+) STARTER INPUT (KEY SIDE OF THE STARTER KILL)
