13
© 2010 Directed Electronics. All rights reserved.
Additional heavy gauge harness wire description
H2/4
RED (+) 30A HIGH CURRENT 12V INPUT
H2/6
RED (+) 30A HIGH CURRENT 12V INPUT
Constant Power and Ignition Wires
Almost all your power and ignition wires can be found behind the key cylinder under the lower driver's side
dash panel. Using the appropriate hand tools, remove the lower dash panel taking care not to break any
parts. If the panel does not come off easily, check for any additional screws you may have missed.
Once the lower dash panel has been removed, locate the ignition harness at the back of the key cylinder. This
is usually a group of heavy gauge wires (approximate 14ga.).
Place the black lead of the LED tester to a clean metal surface in the kick panel area and secure it. Probe one
of the thicker gauge wires. The ignition wire colors of your specific vehicle can be obtained at
www.readyremote.com.
Important: More problems are attributed to poor ground connec-
tions than any other cause. Take extra care to ensure the ground is
a clean metal-to-metal contact and secure.
Testing for Constant Power Wires
Warning! Before making any connection to constant battery power,
make sure that the two 30 amp fuses are removed from the fuse hold-
ers on the two pink 12 VOLT wires. Failure to do so may cause fire or
shorting of sensitive electrical components.
With the key in the off position, test the suspect wire. The constant power wire will read 12V on the multimeter.
Once the constant power wire has been identified, solder the two heavy gauge 12 VOLT RED wires from the
control module to it and wrap the connection with electrical tape.
If the vehicle has two constant power wire, use both of them. Connect one of the heavy gauge RED wires to
one of constant power wires and the other heavy gauge RED wire to the other vehicle constant power wire.
H2/5
PINK/WHITE PROGRAMMABLE OUTPUT, 2nd IGNITION/ACCESSORY CIRCUIT 30A
This wire may be used if vehicle requires more than one ignition. If the vehicle does not require more than
one ignition it can be reprogrammed to act as an accessory wire. This is helpful if there is 1 ignition and 2
accessory wires in the vehicle. See Feature Menu 2 and Programming System Features for instructions on
changing the function of this wire.
