Wiring connections
Main Harness (H1), 9-pin connector
H1/1
LIGHT GREEN BLACK (-) 200mA FACTORY ALARM DISARM
H1/2
GREEN/WHITE (-) 200mA FACTORY ALARM REARM
H1/3
EMPTY NOT USED
H1/4
WHITE/BLUE (-) ACTIVATION INPUT
H1/5
EMPTY NOT USED
H1/6
BROWN (-) 200mA HORN OUTPUT
H1/7
RED/WHITE (-) 200mA TRUNK RELEASE (CHANNEL 2) OUTPUT
H1/8
BLACK GROUND
H1/9
WHITE (+/-) LIGHT FLASH OUTPUT
Heavy gauge relay harness, 6-pin connector
H2/1
PINK OUTPUT TO PRIMARY IGNITION CIRCUIT, 30A (+)
H2/2
PURPLE OUTPUT TO STARTER CIRCUIT, 30A (+)
H2/3
ORANGE OUTPUT TO ACCESSORY CIRCUIT, 30A (+)
H2/4
RED (+) 30A HIGH CURRENT 12V INPUT
H2/5
PINK/WHITE PROGRAMMABLE OUTPUT, 2nd IGNITION/ACCESSORY CIRCUIT 30A
H2/6
RED (+) 30A HIGH CURRENT 12V INPUT
Door lock - 3 pin connector
1
LIGHT BLUE (-) UNLOCK
2
EMPTY NOT USED
3
GREEN (-) LOCK
Auxiliary harness (H3), 5-pin connector
H3/1 BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT
H3/2 VIOLET/WHITE TACHOMETER INPUT WIRE
H3/3 BROWN (+) BRAKE SHUTDOWN INPUT WIRE
H3/4 GRAY (-) HOOD PIN SWITCH SHUTDOWN WIRE
H3/5 BLUE/WHITE (-) 200 mA 2ND STATUS/REAR DEFOGGER
Control button (valet switch), 2-pin connector
1
BLACK INPUT
2
GREY OUTPUT
