Feature menus
Default settings are in bold type.
Menu 1
Feature # Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 Horn function
Off
Siren
20 mS
Siren
30 mS
Siren 40 mS Siren 50 mS
2 Ignition controlled
lock
On
Off
3 Ignition controlled
unlock
On
Off
4 Doorlock output
duration
0.8 sec
.
3.5 sec. 0.4 sec.
5 Double pulse
unlock
Off
On
6 Double pulse lock
Off
On
7 Factory Alarm
Disarm function
with
unlock
Before unlock Remote start only
8 Factory Alarm
Disarm Pulses
Single
Double
9 Comfort Closure Comfort
Closure 1
Off
Comfort Closure 2
10 Panic
On
Off
1. Horn Function
1. Off: turns the lock/unlock horn honk output off, but Panic is still active for 60 seconds
2. On: Opt 2-5, 20-50 mS: sets the lock/unlock horn honk output duration
2. Ign-controlled Lock
1. On: door lock output will activate when ignition is turned on.
2. Off: door lock output will not activate when ignition is turned on.
3. Ignition Controlled Unlock
1. On: door unlock output will activate when the ignition is turned off.
2. Off: door unlock output will not activate when the ignition is turned off.
4. Door Lock Output Duration
1. 0.8sec.: the door lock/unlock pulses for 800mS
2. 3.5sec.: the door lock/unlock pulses for 3.5 seconds
3. 0.4 sec.: the door lock/lock pulses for 400mS
5. Double Pulse Unlock
1. Off: unlock output pulses once
2. On: unlock output pulses twice
6. Double Pulse Lock
1. Off: lock output pulses once
2. On: lock output pulses twice
7. Factory Alarm Disarm function
1. With Unlock: Factory Alarm Disarm wire pulses as programmed, at the same time as the unlock
(Blue) wire, and when remote start is activated.
2. Before Unlock: Factory Alarm Disarm wire will pulse as programmed before the unlock wire, and
